Description
SAM² 6.8 FEATURES
POWERFUL AND AGILE BOSCH PERFORMANCE CX E-DRIVE WITH PURION DISPLAY AND INTEGRATED, REMOVABLE 625 WH BATTERY
170 MM TRAVEL WITH F.O.L.D. KINEMATICS: ROCKSHOX ZEB SUSPENSION FORK WITH 38 MM STANCHION AND SUPERDELUXE REAR SHOCK
FULLY INTEGRATED C.I.S. CABLE ROUTING WITH CRISP SRAM GX EAGLE SHIFTING AND STRONG CODE BRAKES WITH 220 MM ROTORS
DESIGNED FOR DOWN
-
SUPER POWERFUL AND DYNAMIC E-MOTOR
The efficient Bosch Performance CX e-drive (Gen. 4) supports your ride up to 32 km/h with powerful 85 Nm. The strongest e-motor of Bosch is perfectly integrated, the SAM² rides agile and nimble. In eMTB mode, the motor support adjusts automatically to your riding power. Thanks to the integrated, removable 625 Wh battery, you can ride all your trails again and again.
-
OPTIMAL SUSPENSION PERFORMANCE IN ANY SITUATION
Our F.O.L.D. chassis has been specially designed to meet the increased demands placed on e-MTBs. This means that we can also guarantee the perfect mix for the e-Enduro FOCUS SAM²: F.O.L.D. is extremely sensitive while being progressive enough to prevent a harsh bottom out.
-
DESIGNED FOR DOWN
A modern, downhill-oriented geometry, 170 mm travel and fast 29″ wheels make the FOCUS SAM² ready for the roughest trails. The downhill-oriented focus is enhanced by suspension forks with 38 mm stanchions. Additionally, the fully integrated C.I.S. cable routing ensures a clean cockpit and thanks to the FOCUS Flip Chip you have the option to also ride 27,5″ wheels and super short chainstays (430 mm).
SPECIFICATION
FRAME7005 hydroformed aluminium, 3D forging, 170 mm F.O.L.D. kinematic, 148×12 mm thru axle, internal cable routing, post mount 203 mm
FRAME MATERIALAluminium
FORKRock Shox ZEB 29 Boost, Charger R, DebonAir, 110×15 mm, 44 mm rake, 170 mm travel
TRAVEL FORK170 mm
SHOCKRock Shox Super Deluxe Select+, 230/65 mm, hardware: 25,0 x 8 mm
MOTORBosch Performance CX Gen4, 85 Nm, 250 W
BATTERY WATT-HOURS625 Wh
BATTERY AMPERE HOURS16,7 Ah
DISPLAYBosch Purion
SHIFTERSRAM GX Eagle
REAR DERAILLEURSRAM GX Eagle, 12-speed
SPROCKETSRAM PG-1230 Eagle, 12-speed
CHAINSRAM NX Eagle
CRANKSETSamox EC40 ISIS
TRANSMISSION OF DRIVEfront: 34, rear: 10-51
BOTTOM BRACKETIntegrated in Drive Unit
HANDLEBARFOCUS Trail, aluminium, riserbar, 780mm, rise: 30mm, backsweep: 9°
GRIPSFOCUS Locker SL
STEMFOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium
HEADSETACROS ZS56/ZS56, FOCUS C.I.S. Integrated
SADDLEFOCUS Trail SL
SEATPOSTPost Moderne dropper post PM-171, 31.6 mm
