Adjustable Bypass Heavy-Duty Suspension Kit for Ford Ranger PX/PY (2022+, V6 Diesel)

Description

Take your Ford Ranger PY (2022+) V6 Diesel to the next level with the Outback Armour Suspension Kit – engineered for serious off-roaders, tourers, and tradies who demand superior performance, comfort, and durability on and off the road.

Built tough for Australian conditions, this suspension kit is designed to handle the extra weight of accessories like bull bars, winches, canopies, or towing setups – while delivering a smoother, more controlled ride. Whether you’re tackling harsh outback tracks or just want a more capable daily driver, this kit has you covered.

Suspension Kit Front

Assembled Strut Kits – Adjustable Bypass – Expedition HD

Outback Armour suspension kits are designed and engineered in Australia to provide the strength, durability and reliability required for demanding off-road conditions. Adjustable internal bypass provides 20+ stages of velocity sensitive tuning of damping control. Dial in the front and rear adjustments as and when required to suit the accessories or cargo loads, terrain, conditions and personal comfort preferences.

• Increase bypass (-) for comfort

• Decrease bypass (+) for control

This front lift kit includes a pair of assembled struts (including struts, coil springs and strut mounts) ready to install in the vehicle.

• Lift front: 40mm (@ approx 100-150kg load)
• Threaded – height adjustable spring seat
• 20+ settings for damping control
• *Suits steel bullbar & winch

Included Components

Shock Absorbers & Struts Adjustable Bypass – Front Strut OASU0865035-ADJ x2 ea.

Coil Springs Front – Trail/Expedition/Expedition HD OASU1068003 x1 pr.

Strut Mounts Strut Top Mount – Ranger MY22/ Amarok MY23 OASU0758001 x2 ea.

Suspension Kit Rear

Adjustable Bypass – Expedition HD

Outback Armour suspension kits are designed and engineered in Australia to provide the strength, durability and reliability required for demanding off-road conditions. Adjustable internal bypass provides 20+ stages of velocity sensitive tuning of damping control. Dial in the front and rear adjustments as and when required to suit the accessories or cargo loads, terrain, conditions and personal comfort preferences.

• Increase bypass (-) for comfort

• Decrease bypass (+) for control

This complete rear “expedition hd” lift kit suits vehicles with constant load carrying requirements. Refer to the load deflection graph provided to ensure that the vehicle is set up within the appropriate operating range for height and load.

Kit includes: shock absorbers, leaf springs, leaf spring bush kit, centre bearing spacer kit, bump stop strike pad, shackles, pins & u-bolts.

• Lift rear: 50mm (@ approx 500kg load).
• *20+ settings for damping control

Included Components

Shock Absorbers & Struts Adjustable Bypass – Rear Shock OASU0165091-ADJ x2 ea.

Leaf Springs Expedition HD OASU1168006 x2 ea.

U-Bolts U-Bolt (M14 x 62 ID x 240 L) OASU2362006 x4 ea.

Shackles & Pins Greasable Pin OASU2500051 x2 ea. Greasable Shackle – Reverse OASU2400062REV x2 ea.

Bushes Leaf Spring Bush Kit OASU210028K x1 ea.

Correction Components & Parts Bump Stop Striker Pad OASU4268003 x1 kit Centre Bearing Spacer Kit OASU3768002 x1 kit
