Description
INCLUDES
-
Chassis mounted 4.5T Recovery points included
-
4mm bash plate steel
-
Winch Cradle
-
Under wing Side bash plates
-
Removable mesh vents center
-
Removable metal loop included which can hold a 21.5inch LED bar provision
-
Spot light holes cutout in top of bar if not running LED bar metal loop
-
Cutout under number plate for 25inch LED light bar
Please Note:
The 21.5″ and 25″ LED light bars are optional extras and are not included as standard.
If you wish to add a light bar to your order, please leave a comment at checkout. Our team will contact you after your order is placed to confirm details and pricing.
Spot light allocation on top of bar for 3 hole mounting system spotlights.
Sensor cut outs
Only 120mm from front of grill to front of the bullbar.
Can suit up to 12,000lb Low mount Winch.
INCLUDES BASH PLATE
- Made from 8mm steel main winch cradle & 3mm side wings reinforced
- ADR69 compliant and airbag compatible Tested by ASE
- Meets AS4876.1 2002
- Suits most low mount winches up to 12,000LB
- Powder coated in texture black.
- Bash Plate laser cut logo back to mounting points under the bar
- Suits 25inch LED bar
- Standard with antenna cutout in bar.
- It’s a complete bumper replacement making install time frame 4HR
Designed in Australia by Shoreline 4×4 is a WA company Family owned and operated business since 2008
SLX bars meet & exceed the ADR design guidelines, Shoreline 4×4 has completed impact testing in Adelaide passing with our unique ADR impact bracket, which is compatible with each models air bag system.
Complies with Australian standards such as
AS4876.1 2002
Section 5 to ADR 92/00 External projections
Clause 6.5 to ADR 43/04 Vehicle configuration and dimensions
Section 5 of ADR 93/00 Forward Field of View
Clause 6.6 to ADR 43/04 Vehicle configuration and dimensions
Benefits
Designed with maximum airflow to all radiators and intercoolers
All bars are completely sensor & safety compatible with factory systems.
Features
Solid Manufacturing – 1 piece fully welded bar for maximum toughness
Low profile design- our frontal protection bars are only 80-120mm depending on the model from the front of the grill.
Loaded with features- our bars include recovery points, bash plates to cross member, under wing bash plates, winch cradles, LED bar provisions & LED lights.
Longevity – Our bars are made with premium 400SS grade steel, after manufacture they are acid washed zinc primed and powder coated in semi gloss matt black.
Protection – 3 bash plates included, front and side under wing.
Recovery Points – Recovery points are rated to 4500kg
