TAG Adjustable Heavy-Duty Tow Ball Mount – 90° Vertical Face, 50mm Square Receiver

Description

The TAG Adjustable Tow Ball Mount features a heavy-duty 50mm square shank with multiple pin holes for horizontal and vertical adjustment to suit your towing setup. For full compatibility, the unit includes a reducer allowing the use of a 70mm or 50mm tow ball. Made from solid steel with a durable powder-coated finish that resists rust, corrosion, and chipping.

• 90° Separate Tongue Face with four adjustable positions.

• Drop 115mm

• Can be mounted in Drop Mode or Rise Mode to raise or lower the tow ball

• Fits 70mm tow ball (or 50mm tow ball using included reducer)

• Gross Trailer Weight 4500kg (70mm Tow Ball) / 3500kg (50mm Tow Ball)

• Ball Weight 450kg (70mm Tow Ball) / 350kg (50mm Tow Ball)

• Durable Powder Coated Finish

• ADR 62/02 Compliant

• TAG Limited Lifetime Warranty

  Tow Ball, R-Clip & Hitch Pin are sold separately. Always check your vehicle and towbar’s maximum towing capacity.

• Ensure you tighten Allen key grub screw before main attachment bolts.

• Torque spec on bolts that attach head to shank is 280nm.

• Ball Weight [kg]: 450
• Tow Ball Mount Class: Heavy Duty (Class 4)
• Gross Trailer Weight: 4500
• Hitch Type: Heavy Duty 50mm Square
• Drop: 285mm
• Rise: 160
• Tongue Face: 90°
• Coating: Powder Coated
• Adjustable: Adjustable
• Material Type: Solid Steel
